テーパーローラーベアリング主要規格表
| 呼び番号 | d | D | B | C | T | 内輪 r1,r2 (最小） |
外輪 r3,r4 (最小) |
注文(外部サイトへ移動) |
| 28985 | 60.325 | 100 | 25.4 | 19.845 | 25.4 | 3.5 | 3.3 |  |
| 30204J | 20 | 47 | 14 | 12 | 15.25 | 1 | 1 | 在庫無 |
| 30205J | 25 | 52 | 15 | 13 | 16.25 | 1 | 1 | |
| 30206J | 30 | 62 | 16 | 14 | 17.25 | 1 | 1 | |
| 30207J | 35 | 72 | 17 | 15 | 18.25 | 1.5 | 1.5 | |
| 30208J | 40 | 80 | 18 | 16 | 19.75 | 1.5 | 1.5 | |
| 30209J | 45 | 85 | 19 | 16 | 20.75 | 1.5 | 1.5 | |
| 30210J | 50 | 90 | 20 | 17 | 21.75 | 1.5 | 1.5 | 在庫無 |
| 30211J | 55 | 100 | 21 | 18 | 22.75 | 2 | 1.5 | |
| 30212J | 60 | 110 | 22 | 19 | 23.75 | 2 | 1.5 | 在庫無 |
| 30213J | 65 | 120 | 23 | 20 | 24.75 | 2 | 1.5 | |
| 30306CH4 | 30 | 72 | 19 | 14 | 20.75 | 1.5 | 1.5 | |
| 30314J | 70 | 150 | 35 | 30 | 38 | 3 | 3 | 在庫無 |
| 30314JH4 | 70 | 150 | 35 | 30 | 38 | 3 | 2.5 | 在庫無 |
| 31308JgH4 | 40 | 90 | 23 | 17 | 25.25 | 2 | 1.5 | 在庫無 |
| 31310JgH4 | 50 | 110 | 27 | 19 | 29.25 | 2 | 2 | 在庫無 |
| 31311JgH4 | 55 | 120 | 29 | 21 | 31.5 | 2.5 | 2 | |
| 32005XJAPCmH4 | 25 | 47 | 15 | 11.5 | 15 | 0.6 | 0.6 | |
| 32006XJgH46X | 30 | 55 | 17 | 13 | 17 | 1 | 1 | |
| 32007XJgH46X | 35 | 62 | 18 | 14 | 18 | 1 | 1 | |
| 32008XJ | 40 | 68 | 19 | 14.5 | 19 | 1 | 1 | |
| 32009XJ | 45 | 75 | 20 | 15.5 | 20 | 1 | 1 | |
| 32011XJ2 | 55 | 90 | 23 | 19.25 | 24.75 | 3.5 4.5 |
1.5 | |
| 32206J | 30 | 62 | 20 | 17 | 21.25 | 1 | 1 | |
| 32207J | 35 | 72 | 23 | 19 | 24.25 | 1.5 | 1.5 | |
| 32212J | 60 | 110 | 28 | 24 | 29.75 | 2 | 1.5 | 在庫無 |
| 32213J | 65 | 120 | 31 | 27 | 32.75 | 2 | 1.5 | |
| 32215J | 75 | 130 | 31 | 27 | 33.25 | 2 | 1.5 | |
| 32216JgH4 | 80 | 140 | 33 | 28 | 35.25 | 2.5 | 2 | |
| 32217J | 85 | 150 | 36 | 30 | 38.5 | 2.5 | 2 | |
| 32218J | 90 | 160 | 40 | 34 | 42.5 | 2.5 | 2 | 在庫無 |
| 32219J | 95 | 170 | 43 | 37 | 45.5 | 3 | 2.5 | |
| 32307CgH4 | 35 | 80 | 31 | 24 | 32.75 | 2 | 1.5 | |
| 32310J | 50 | 110 | 40 | 33 | 42.25 | 2.5 | 2 | |
| 32311JH4 | 55 | 120 | 43 | 35 | 45.5 | 2.5 | 2 | |
| 33017J | 85 | 130 | 36 | 29.5 | 36 | 1 | 1 | |
| 33022J | 110 | 170 | 47 | 37 | 47 | 2.5 | 2 | |
| 33108H4 | 40 | 75 | 26 | 20.5 | 26 | 1.5 | 1.5 | |
| 33115J | 75 | 125 | 37 | 29 | 37 | 2 | 1.5 | |
| 332/28JH4 | 28 | 58 | 24 | 19 | 24 | 1 | 1 | |
| 33206J | 30 | 62 | 25 | 19.5 | 25 | 1 | 1 | |
| 33208J | 40 | 80 | 32 | 25 | 32 | 1.5 | 1.5 | 在庫無 |
| 3780f | 50 | 93.264 | 30.302 | 23.813 | 30.163 | 3.6 | 3.3 | |
| 594A | 95.25 | 152.4 | 36.322 | 30.163 | 39.688 | 5.1 | 3.3 | 在庫無 |
| E32010XJH4 | 50 | 80 | 20 | 15.5 | 20 | 1 | 1 | |
| HH224335 | 101.6 | 212.725 | 66.675 | 53.975 | 66.675 | 7 | 3.3 | 在庫無 |
| HM212049 | 66.675 | 122.238 | 38.354 | 29.718 | 38.1 | 3.5 | 3.3 | |
| HM218248 | 89.975 | 146.975 | 40 | 32.5 | 40 | 7 | 3.5 | 在庫無 |
| HM89249gH | 36.512 | 79.375 | 28.829 | 22.664 | 29.37 | 3.5 | 3.3 | |
| JL69349 | 38 | 63 | 17 | 13.5 | 17 | 3.5 | 1.3 | |
| L44649 | 26.988 | 50.292 | 14.732 | 10.668 | 14.224 | 3.5 | 1.3 | |
| L68149 | 34.988 | 60 | 16.764 | 11.938 | 15.875 | 3.6 4.8 |
1.3 | |
| LM102949 | 45.242 | 73.431 | 19.812 | 15.748 | 19.558 | 3.5 | 0.8 | 在庫無 |
| LM104949 | 50.8 | 82.55 | 22.225 | 16.51 | 21.59 | 3.6 | 1.3 | |
| LM11749 | 17.462 | 39.878 | 14.605 | 10.668 | 13.843 | 1.3 | 1.3 | |
| LM11949 | 19.05 | 45.237 | 16.637 | 12.065 | 15.494 | 1.3 | 1.3 | 在庫無 |
| M12649 | 21.43 | 50.005 | 18.288 | 13.97 | 17.526 | 1.3 | 1.3 | |
| M802048gH | 41.275 | 82.55 | 25.654 | 20.193 | 26.543 | 3.6 | 3.3 | |
| ST-285216 | 28 | 52 | 18.5 | 12 | 16 | 3.6 | 1.8 | |
| ST-306216 | 30.162 | 62 | 16.566 | 12 | 16.002 | 3.5 | 1 | 在庫無 |
| ST-306217APC | 30 | 62 | 17.7 | 13.3 | 17.7 | 1 | 1 | 在庫無 |
| ST-307219PC | 30 | 72 | 18.3 | 14.95 | 19 | 1.5 | 1.5 | 在庫無 |
| ST-327221 | 32 | 72 | 20 | 15.5 | 21.75 | 2 | 2 | 在庫無 |
| ST-356216APC | 35 | 62 | 14.8 | 12 | 16 | 1 | 1 | 在庫無 |
| ST-357219 | 35 | 72 | 17 | 16.5 | 19.75 | 2.6 | 1.5 | 在庫無 |
| ST-386518 | 38.1 | 65.088 | 21.139 | 13.97 | 18.034 | 3.56 4.75 |
1.3 | |
| ST-406822 | 40 | 68 | 22 | 18 | 22 | 1 | 1 | 在庫無 |
| ST-458020H4 | 45.23 | 80 | 19 | 16.5 | 20.5 | 1 | 1 | |
| ST-5011444 | 50 | 114.3 | 44.45 | 34.925 | 44.45 | 3.5 | 3.3 | 在庫無 |
| ST-5510032 | 55 | 100 | 31 | 24.5 | 32 | 2 | 2 | 在庫無 |
| ST-6513051 | 65 | 130 | 48 | 39 | 51 | 2.5 | 2.5 | |
| ST-9015038 | 90 | 150 | 36 | 30 | 38.5 | 2.5 | 2.5 | |
| ST-9516042 | 95 | 160 | 40 | 34 | 42.5 | 4 | 3 | |
| ST-E336221PC | 33 | 62 | 21 | 14.5 | 21 | 1 | 1 | 在庫無 |
| ST-E356521PC | 35 | 65 | 20 | 17 | 21 | 1 | 1 | 在庫無 |
| ST-E357228H4 | 35 | 72 | 28.75 | 22 | 28.75 | 1.5 | 1.5 | 在庫無 |
| ST-HE417119PC | 41 | 71 | 19 | 14.5 | 19 | 1.5 | 1 | 在庫無 |
| 32912JH4 | 60 | 85 | 17 | 14 | 17 | 1 | 1 | |
| L45449 | 29 | 50.292 | 14.732 | 10.668 | 14.224 | 3.6 | 1.3 | |
| LM48548 | 34.925 | 65.088 | 18.288 | 13.97 | 18.034 | 3.5 | 1.3 | |
| LM501349 | 41.275 | 73.431 | 19.812 | 16.604 | 21.43 | 3.6 | 0.8 | |
| M88043A | 30.162 | 68.262 | 22.225 | 17.462 | 22.225 | 2.3 | 1.5 | |
| 31314JgH5 | 70 | 150 | 35 | 25 | 38 | 3 | 2.5 | |
| LM603049 | 45.242 | 77.788 | 19.842 | 16.668 | 21.43 | 3.6 | 0.8 | |
